「快速門定做」簽訂石家莊普泰爾公司堆積門項目


"Customized Fast Gate" Signed Shijiazhuang Putaier's Accumulated Gate Project

龍盛門業擁有先進的生產設備，并引進國外最新生產技術，在國內快速門制造業享有一定聲譽，與眾多知名地產公司和企業合作。


Longshengmen has advanced production equipment and imports the latest production technology from abroad. It enjoys a certain reputation in domestic express door manufacturing industry and cooperates with many well-known real estate companies and enterprises.


本地與普泰爾公司合作廠房快速門項目，地點位于石家莊市，右石家莊辦事處工作人員進行量尺，并負責安裝及售后工作。


The project is located in Shijiazhuang City. The staff of the right Shijiazhuang office are responsible for the installation and after-sales work.


本項目快速門尺寸為3.5米寬，7.9米高，共六樘。


The size of the fast door of this project is 3.5 meters wide and 7.9 meters high, totaling six diaphragms.

配置說明：


Configuration description:


1、框架材質：4.0mm厚銀白工業鋁合金立柱。


1. Frame material: 4.0mm thick silver-white industrial aluminium alloy column.


2、簾布：高密度聚錄乙烯涂層熱熔織物，材料厚度0.8mm-1.0mm,多色可選。


2. Curtain cloth: high density polyvinyl film coated hot melt fabric, material thickness 0.8mm-1.0mm, multi-color optional.


3、動力系統：IP54專用剎車制動馬達，1.5KW220V或三相四電，快速專用電機，變頻器，行程編碼器，微電腦變頻控制電箱（三菱CPU）


3. Power system: IP54 special brake motor, 1.5KW220V or three-phase four-power, fast special motor, frequency converter, stroke encoder, microcomputer frequency conversion control unit (Mitsubishi CPU)


4、門體運行速度：0.8--1.5m/s  （變頻可調速）


4. Door speed: 0.8-1.5m/s (variable frequency adjustable speed)


5、安全保護：保護控制關斷開關火三相電源保護；控制操作電路保護。溫敏斷電器電機保護。


5. Safety protection: protection, control, switching off, three-phase power supply protection, control and operation circuit protection. Temperature-sensitive breaker motor protection.


6、門梁抗拉強度 ：175kn/m


6. Tensile Strength of Door Beam: 175kn/m


7、使用溫度：-10℃+70℃/超耐寒區域--40℃


7. Service temperature: -10 C+70 C/Ultra-cold-resistant area-40 C


8、透明視窗：PVC透明軟板，材料厚度1.0mm，增加安全及管理方便性，配整體橫向透明視窗。


8. Transparent window: PVC transparent soft board, material thickness 1.0 mm, increase safety and management convenience, with the overall transverse transparent window.


9、抗風能力：25m/s配鋁合金抗風筋。


9. Wind resistance: 25m/s with aluminum alloy wind bar.


10、密封性能：底端裝有彈性的PVC基布，可與不平坦的地面緊密貼合。


10. Sealing performance: The bottom is equipped with elastic PVC base cloth, which can be closely bonded with uneven ground.


11、安全配置：標準紅外線光電保護、警示燈、防撞柱、停電手動搖桿。


11. Safety Configuration: Standard infrared photoelectric protection, warning lights, anti-collision column, power failure manual rocker.
